Panel / Chassis Mount Resistors:
6.203 gevonden productenVind een enorm aanbod van Panel / Chassis Mount Resistors in Farnell Nederland. We hebben een grote selectie van Panel / Chassis Mount Resistors op voorraad, waaronder nieuwe en populairste producten van 's werelds beste fabrikanten, waaronder: CGS - Te Connectivity, Ohmite, Arcol, TT Electronics / Welwyn & Multicomp Pro.
Weergeven
Koper
Ingenieur
Fabrikant
Resistance
Product Range
Power Rating
Resistor Case / Package
Resistance Tolerance
Resistor Terminals
Voltage Rating
Resistor Technology
Temperature Coefficient
Resistor Type
Resistor Mounting
Product Length
Product Width
Product Height
Operating Temperature Min
Operating Temperature Max
Qualification
Verpakking
Geen filter(s) toegepast
0 Filter(s) geselecteerd
| Vergelijken | Prijs voor | Hoeveelheid | ||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Each | 1+ € 116,040 10+ € 90,170 20+ € 84,550 | Totaal:€ 116,04 Min: 1 / Meerdere: 1 | 10ohm | RTOP Series | 200W | - | ± 5% | Screw | 1.5kV | Thick Film | ± 150ppm/°C | High Power | Panel Mount | 38mm | 25mm | 12.6mm | -55°C | 125°C | - | |||||
Each | 1+ € 1,260 3+ € 1,020 5+ € 0,979 10+ € 0,938 20+ € 0,879 Meer prijzen... | Totaal:€ 1,26 Min: 1 / Meerdere: 1 | 47ohm | SQ Series | 20W | Radial Leaded | ± 5% | Quick Connect | - | Wirewound | ± 300ppm/°C | High Power | Panel Mount | - | - | - | -55°C | 250°C | - | |||||
TT ELECTRONICS / WELWYN | Each | 1+ € 3,060 50+ € 2,380 100+ € 2,180 250+ € 1,740 500+ € 1,290 | Totaal:€ 3,06 Min: 1 / Meerdere: 1 | 33ohm | WPRT Series | 20W | - | ± 5% | Solder Lug | - | Wirewound | ± 350ppm/°C | High Power, Flame Proof | Panel Mount | 63mm | 12.5mm | 13.5mm | -55°C | 155°C | AEC-Q200 | ||||
TT ELECTRONICS / WELWYN | Each | 1+ € 20,910 3+ € 14,050 5+ € 12,510 10+ € 10,960 20+ € 9,500 Meer prijzen... | Totaal:€ 20,91 Min: 1 / Meerdere: 1 | 2.7ohm | WH Series | 100W | - | ± 5% | Solder Lug | 1.9kV | Wirewound | ± 100ppm/°C | High Power | Panel Mount | 65.2mm | 47.5mm | 24.1mm | -55°C | 200°C | - | ||||
Each | 1+ € 8,800 10+ € 6,300 100+ € 5,060 500+ € 4,300 1000+ € 4,210 Meer prijzen... | Totaal:€ 8,80 Min: 1 / Meerdere: 1 | 6.8ohm | SH Series | 50W | - | ± 5% | Solder Lug | 1.285kV | Wirewound | ± 50ppm/°C | High Power | Panel Mount | 50mm | 29.4mm | 15mm | -55°C | 200°C | - | |||||
TT ELECTRONICS / WELWYN | Each | 1+ € 22,350 3+ € 15,020 5+ € 13,370 10+ € 11,710 20+ € 10,160 Meer prijzen... | Totaal:€ 22,35 Min: 1 / Meerdere: 1 | 15ohm | WH Series | 100W | - | ± 5% | Solder Lug | 1.9kV | Wirewound | ± 100ppm/°C | High Power | Panel Mount | 65.2mm | 47.5mm | 24.1mm | -55°C | 200°C | - | ||||
TT ELECTRONICS / WELWYN | Each | 1+ € 39,890 5+ € 34,120 10+ € 28,340 20+ € 27,430 40+ € 26,520 Meer prijzen... | Totaal:€ 39,89 Min: 1 / Meerdere: 1 | 22ohm | WDBR Series | 1.5kW | - | ± 10% | Quick Connect | 2.5kV | Thick Film | +500ppm/°C to +600ppm/°C | Low Profile | - | 49.3mm | 35.9mm | 0.9mm | -55°C | 200°C | - | ||||
TT ELECTRONICS / WELWYN | Each | 1+ € 10,540 5+ € 9,120 10+ € 6,530 25+ € 5,340 50+ € 5,170 Meer prijzen... | Totaal:€ 10,54 Min: 1 / Meerdere: 1 | 0.68ohm | WH Series | 50W | - | ± 5% | Solder Lug | 1.25kV | Wirewound | ± 50ppm/°C | High Power | Panel Mount | 51mm | 30mm | 16mm | -55°C | 275°C | - | ||||
TT ELECTRONICS / WELWYN | Each | 1+ € 28,510 3+ € 24,300 5+ € 20,590 10+ € 19,230 20+ € 17,860 Meer prijzen... | Totaal:€ 28,51 Min: 1 / Meerdere: 1 | 68ohm | WH Series | 100W | - | ± 5% | Solder Lug | 1.9kV | Wirewound | ± 100ppm/°C | High Power | Panel Mount | 65.2mm | 47.5mm | 24.1mm | -55°C | 200°C | - | ||||
Each | 1+ € 54,590 | Totaal:€ 54,59 Min: 1 / Meerdere: 1 | 470ohm | RPH 100 Series | 100W | - | ± 5% | Screw | 1.9kV | Thick Film | ± 150ppm/°C | High Power | Panel Mount | 65.2mm | 46.7mm | 21.15mm | -55°C | 125°C | - | |||||
TT ELECTRONICS / WELWYN | Each | 1+ € 11,110 5+ € 8,760 10+ € 7,470 25+ € 6,330 50+ € 5,490 Meer prijzen... | Totaal:€ 11,11 Min: 1 / Meerdere: 1 | 0.33ohm | WH Series | 50W | - | ± 5% | Solder Lug | 1.25kV | Wirewound | ± 50ppm/°C | High Power | Panel Mount | 51mm | 30mm | 16mm | -55°C | 275°C | - | ||||
TT ELECTRONICS / WELWYN | Each | 1+ € 5,940 5+ € 4,640 10+ € 3,660 25+ € 3,120 | Totaal:€ 5,94 Min: 1 / Meerdere: 1 | 620ohm | WH Series | 50W | - | ± 5% | Solder Lug | 1.25kV | Wirewound | ± 50ppm/°C | High Power | Panel Mount | 51mm | 30mm | 16mm | -55°C | 275°C | - | ||||
TT ELECTRONICS / WELWYN | Each | 1+ € 5,870 10+ € 3,910 25+ € 3,410 50+ € 3,140 100+ € 2,630 Meer prijzen... | Totaal:€ 5,87 Min: 1 / Meerdere: 1 | 1kohm | WH Series | 15W | - | ± 5% | Solder Lug | 265V | Wirewound | ± 50ppm/°C | High Power | Panel Mount | 21mm | 21mm | 11mm | -55°C | 275°C | - | ||||
TT ELECTRONICS / WELWYN | Each | 1+ € 56,910 10+ € 36,540 20+ € 35,810 | Totaal:€ 56,91 Min: 1 / Meerdere: 1 | 220ohm | WH Series | 300W | - | ± 5% | Threaded Stud | 2.5kV | Wirewound | ± 100ppm/°C | High Power | Panel Mount | 127.7mm | 72.5mm | 41.8mm | -55°C | 200°C | - | ||||
TT ELECTRONICS / WELWYN | Each | 1+ € 10,540 5+ € 10,100 10+ € 6,540 25+ € 5,650 50+ € 5,180 Meer prijzen... | Totaal:€ 10,54 Min: 1 / Meerdere: 1 | 30ohm | WH Series | 50W | - | ± 5% | Solder Lug | 1.25kV | Wirewound | ± 50ppm/°C | High Power | Panel Mount | 51mm | 30mm | 16mm | -55°C | 275°C | - | ||||
CGS - TE CONNECTIVITY | Each | 1+ € 41,890 10+ € 32,340 20+ € 31,690 | Totaal:€ 41,89 Min: 1 / Meerdere: 1 | 33ohm | TJT Series | 150W | - | ± 5% | Wire Leaded | - | - | ± 260ppm/°C | High Reliability, High Stability | Chassis Mount | 120mm | 80mm | 10mm | -25°C | 250°C | - | ||||
Each | 1+ € 3,180 5+ € 2,750 10+ € 2,490 25+ € 2,000 50+ € 1,790 | Totaal:€ 3,18 Min: 1 / Meerdere: 1 | 56ohm | HS Series | 16W | - | ± 5% | Solder Lug | 265V | Wirewound | ± 50ppm/°C | High Power | Chassis Mount | 21mm | 21mm | 11mm | - | - | - | |||||
Each | 1+ € 16,460 10+ € 11,660 | Totaal:€ 16,46 Min: 1 / Meerdere: 1 | 0.56ohm | TE Series | 80W | - | ± 5% | Solder Lug | - | Wirewound | ± 400ppm/°C | High Power | Chassis Mount | 152mm | - | - | -25°C | 225°C | - | |||||
Each | 1+ € 51,990 10+ € 40,360 20+ € 39,550 | Totaal:€ 51,99 Min: 1 / Meerdere: 1 | 22ohm | TE Series | 400W | - | ± 5% | Solder Lug | 2.5kV | Wirewound | ± 300ppm/°C | High Power | Chassis Mount | 282mm | - | - | -25°C | 225°C | - | |||||
Each | 1+ € 16,520 | Totaal:€ 16,52 Min: 1 / Meerdere: 1 | 22ohm | TE Series | 100W | - | ± 5% | Solder Lug | - | Wirewound | ± 300ppm/°C | High Power | Chassis Mount | 182mm | - | - | -25°C | 225°C | - | |||||
Each | 1+ € 17,140 | Totaal:€ 17,14 Min: 1 / Meerdere: 1 | 22ohm | TE Series | 120W | - | ± 5% | Solder Lug | - | Wirewound | ± 300ppm/°C | High Power | Chassis Mount | 182mm | - | - | -25°C | 225°C | - | |||||
Each | 1+ € 13,990 10+ € 9,910 | Totaal:€ 13,99 Min: 1 / Meerdere: 1 | 0.27ohm | TE Series | 80W | - | ± 5% | Solder Lug | - | Wirewound | ± 400ppm/°C | High Power | Chassis Mount | 152mm | - | - | -25°C | 225°C | - | |||||
CGS - TE CONNECTIVITY | Each | 1+ € 89,180 10+ € 65,860 20+ € 61,150 | Totaal:€ 89,18 Min: 1 / Meerdere: 1 | 22ohm | HCH Series | 400W | - | ± 5% | Wire Leaded | 1.1kV | Wirewound | ± 200ppm/°C | High Power | Chassis Mount | 265mm | 60mm | 31mm | - | 350°C | - | ||||
CGS - TE CONNECTIVITY | Each | 1+ € 97,070 | Totaal:€ 97,07 Min: 1 / Meerdere: 1 | 82ohm | HCH Series | 500W | - | ± 5% | Wire Leaded | 1.1kV | Wirewound | ± 200ppm/°C | High Power | Chassis Mount | 335mm | 60mm | 31mm | - | 375°C | - | ||||
Each | 1+ € 14,530 | Totaal:€ 14,53 Min: 1 / Meerdere: 1 | 2.2kohm | TE Series | 50W | - | ± 5% | Solder Lug | - | Wirewound | ± 300ppm/°C | High Power | Chassis Mount | 102mm | - | - | -25°C | 225°C | - | |||||
