Chip SMD Resistors

: 195,030 Products Found

Filter Layout: LEFT

TOP

Contract pricing display is unavailable at the moment. Prices shown are standard retail prices, orders placed will have contract pricing applied when processed.

Open Filters

We offer a wide range of Metal Film, Metal Foil, and Thick Film chip SMD resistors, with resistance values from 0.003Ω to 50GΩ and power ratings from 30mW to 50W.

How do I choose a chip SMD resistor?

Chip SMD resistors are commonly used for pull-up/pull-down operations to ensure a signal is at valid logic level when external devices are removed, voltage divisions, current limiting, and filtering signals at certain frequencies in high-pass/low-pass/band-pass filters. You can use 0Ω resistors as jumpers to disable a sub-section of a circuit. There are three kinds of Chip SMD Resistors:

Thin Film or Metal Film resistors are used in high precision applications like audio, medical, or test equipment. They have lower variation (0.1%-2%), a lower temperature coefficient (5 ppm/K), and are less noisy compared to thick film resistors. However, they are more expensive.
Thick Film resistors are the most common type of resistor, and are used for most applications. They have higher variation (1%-5%), a higher temperature coefficient (50 ppm/K), and are noisier than thin film resistors. If there are no specific performance requirements, thick film resistors are usually the preferred choice.
There are also Metal Foil resistors which provide high rated power and excellent load life stability along with extremely low Temperature Coefficient of Resistance (TCR).

SMD resistor sizes

The shape and size of chip SMD resistors are standardized, with most manufacturers using the JEDEC standards. The size of chip SMD resistors is indicated by a numerical code, such as 0603. This code contains the length and width of the package. So, the imperial code 0603 indicates a length of 0.060" and a width of 0.030".

Although SMD package codes can be given in either imperial or metric units, the imperial code is used more often to indicate the package size. Confusingly, even when the imperial naming convention is used, the metric dimensions are often used during the design of the printed circuit boards (PCBs). In general, you can assume the code is in imperial units, but the dimensions used are in mm. The SMD resistor size used depends primarily on the required power rating, the minimum feature size of the PCB manufacturing, and the limitations of the pick-and-place equipment.

Compare Selected Compare (0)

Sort by

Best Match

Best Match Price: Low to High Price: High to Low Stock: Low to High Stock: High to Low

Manufacturer Part No	Order Code	Description / Manufacturer	Price For	Price	Quantity	Resistance	Resistor Element Material	Power Rating	Resistor Case / Package	Resistance Tolerance	Resistor Technology	Resistor Type	Product Range	Voltage Rating	Temperature Coefficient	Product Length	Product Width	Operating Temperature Min	Operating Temperature Max	Qualification
						Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending
CRCW080510K0FKEA	2123255 Data Sheet + RoHS Date/Lot Code	SMD Chip Resistor, 10 kohm, ± 1%, 125 mW, 0805 [2012 Metric], Thick Film, General Purpose VISHAY You previously purchased this product. View in Order History	Each (Supplied on Full Reel) Full Reel Packaging Options Suggested replacement for:2123255 1469856RL in Re-Reel 1469856 in Cut Tape	5000+ €0.0102 25000+ €0.01 50000+ €0.0098	Restricted Item Minimum order of 5000 items Multiples of 5000 only Please enter a valid quantity Add Min: 5000 Mult: 5000	10kohm	-	125mW	0805 [2012 Metric]	± 1%	Thick Film	General Purpose	CRCW e3 Series	150V	± 100ppm/K	2mm	1.25mm	-55°C	155°C	AEC-Q200
CRCW080522R0FKEA	1652962 Data Sheet + RoHS Date/Lot Code	SMD Chip Resistor, 22 ohm, ± 1%, 125 mW, 0805 [2012 Metric], Thick Film, General Purpose VISHAY You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:1652962 1652962RL in Re-Reel	10+ €0.0748 100+ €0.0299 500+ €0.0224 1000+ €0.0148 2500+ €0.0122 5000+ €0.012 25000+ €0.0117 50000+ €0.0115 More Pricing...	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	22ohm	-	125mW	0805 [2012 Metric]	± 1%	Thick Film	General Purpose	CRCW e3 Series	150V	± 100ppm/K	2mm	1.25mm	-55°C	155°C	AEC-Q200
ERA3AEB302V	1670182 Data Sheet + RoHS	SMD Chip Resistor, 3 kohm, ± 0.1%, 100 mW, 0603 [1608 Metric], Metal Film (Thin Film) PANASONIC You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:1670182 1811517 in Full Reel	10+ €0.311 100+ €0.12 500+ €0.0999 1000+ €0.0666 2500+ €0.0653	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	3kohm	-	100mW	0603 [1608 Metric]	± 0.1%	Metal Film (Thin Film)	High Reliability	ERA Series	75V	± 25ppm/°C	1.6mm	0.85mm	-55°C	155°C	AEC-Q200
ERJ3EKF2493V	2059513 Data Sheet + RoHS Date/Lot Code	SMD Chip Resistor, 249 kohm, ± 1%, 100 mW, 0603 [1608 Metric], Thick Film, Precision PANASONIC You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:2059513 2059513RL in Re-Reel	10+ €0.0538 100+ €0.0219 500+ €0.0154 1000+ €0.0089 2500+ €0.0087 5000+ €0.0085 25000+ €0.0084 50000+ €0.0082 More Pricing...	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	249kohm	-	100mW	0603 [1608 Metric]	± 1%	Thick Film	Precision	ERJ Series	75V	± 100ppm/°C	1.6mm	0.85mm	-55°C	155°C	AEC-Q200
MCMR04X4702FTL	2073065 Data Sheet + RoHS	SMD Chip Resistor, Ceramic, 47 kohm, ± 1%, 62.5 mW, 0402 [1005 Metric], Thick Film MULTICOMP PRO You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:2073065 2073065RL in Re-Reel 2692096 in Full Reel	10+ €0.012 100+ €0.0048 500+ €0.0024 2500+ €0.0023 5000+ €0.0022	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	47kohm	-	62.5mW	0402 [1005 Metric]	± 1%	Thick Film	Sulfur Resistant	-	-	± 100ppm/°C	1.02mm	0.5mm	-55°C	155°C	AEC-Q200

RC1206FR-071R5L	9236546 Data Sheet + RoHS	SMD Chip Resistor, 1.5 ohm, ± 1%, 250 mW, 1206 [3216 Metric], Thick Film, General Purpose YAGEO You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:9236546 9236546RL in Re-Reel	10+ €0.118 100+ €0.0522 500+ €0.0512 1000+ €0.0501 2500+ €0.0442 5000+ €0.0432 25000+ €0.0376 50000+ €0.0321 More Pricing...	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	1.5ohm	-	250mW	1206 [3216 Metric]	± 1%	Thick Film	General Purpose	RC_L Series	-	± 200ppm/°C	3.1mm	1.6mm	-55°C	155°C	-

CRCW0603560RFKEA	1469828 Data Sheet + RoHS Date/Lot Code	SMD Chip Resistor, 560 ohm, ± 1%, 100 mW, 0603 [1608 Metric], Thick Film, General Purpose VISHAY You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:1469828 1469828RL in Re-Reel	10+ €0.0421 100+ €0.0174 500+ €0.0145 1000+ €0.0078 2500+ €0.0076 5000+ €0.0075 25000+ €0.0073 50000+ €0.0072 More Pricing...	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	560ohm	-	100mW	0603 [1608 Metric]	± 1%	Thick Film	General Purpose	CRCW e3 Series	75V	± 100ppm/K	1.55mm	0.85mm	-55°C	155°C	AEC-Q200

CR0603-FX-1000ELF	2008332 Data Sheet Data Sheet + RoHS Date/Lot Code	SMD Chip Resistor, 100 ohm, ± 1%, 100 mW, 0603 [1608 Metric], Thick Film, General Purpose BOURNS You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:2008332 2008332RL in Re-Reel 2691847 in Full Reel	10+ €0.0192 100+ €0.0095 500+ €0.0082 1000+ €0.0047 2500+ €0.0046	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	100ohm	-	100mW	0603 [1608 Metric]	± 1%	Thick Film	General Purpose	CR Series	-	± 100ppm/°C	1.6mm	0.85mm	-55°C	155°C	-

RL0402FR-070R1L	1284586 Data Sheet + RoHS	SMD Chip Resistor, 0.1 ohm, ± 1%, 62.5 mW, 0402 [1005 Metric], Thick Film, General Purpose YAGEO You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:1284586 1284586RL in Re-Reel	10+ €0.378 100+ €0.146 500+ €0.0785 2500+ €0.0734 5000+ €0.0673 10000+ €0.066 50000+ €0.0646 100000+ €0.0633 More Pricing...	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	0.1ohm	-	62.5mW	0402 [1005 Metric]	± 1%	Thick Film	General Purpose	RL Series	-	± 800ppm/°C	1mm	0.5mm	-55°C	125°C	-

CRG0402F100R	2331443 Data Sheet + RoHS	SMD Chip Resistor, 100 ohm, ± 1%, 62.5 mW, 0402 [1005 Metric], Thick Film, General Purpose TE CONNECTIVITY You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:2331443 2331443RL in Re-Reel 2692931 in Full Reel	10+ €0.0323 100+ €0.0132 500+ €0.0069 2500+ €0.0045 5000+ €0.0044	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	100ohm	-	62.5mW	0402 [1005 Metric]	± 1%	Thick Film	General Purpose	CRG Series	-	± 100ppm/°C	1.02mm	0.5mm	-55°C	125°C	-

MCSR08X100 JTL	2074330 Data Sheet + RoHS	SMD Chip Resistor, 10 ohm, ± 5%, 125 mW, 0805 [2012 Metric], Thick Film, Sulfur Resistant MULTICOMP PRO You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:2074330 2074330RL in Re-Reel	10+ €0.0205 100+ €0.0182 500+ €0.0126 1000+ €0.0086 2500+ €0.0066 5000+ €0.0059 25000+ €0.0042 50000+ €0.0038 More Pricing...	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	10ohm	-	125mW	0805 [2012 Metric]	± 5%	Thick Film	Sulfur Resistant	-	150V	± 100ppm/°C	2.01mm	1.25mm	-55°C	155°C	AEC-Q200

ASC0402-4K7FT10	2078865 Data Sheet Data Sheet + RoHS Date/Lot Code	SMD Chip Resistor, 4.7 kohm, ± 1%, 62.5 mW, 0402 [1005 Metric], Thick Film, Sulfur Resistant TT ELECTRONICS / WELWYN You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:2078865 2078865RL in Re-Reel	10+ €0.0735 100+ €0.0355 500+ €0.0148 2500+ €0.0122 5000+ €0.0102 10000+ €0.01 50000+ €0.0098 100000+ €0.0096 More Pricing...	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	4.7kohm	-	62.5mW	0402 [1005 Metric]	± 1%	Thick Film	Sulfur Resistant	ASC Series	-	± 100ppm/°C	1.02mm	0.5mm	-55°C	155°C	-

ERA3AEB203V	1670194RL Data Sheet + RoHS Date/Lot Code	SMD Chip Resistor, 20 kohm, ± 0.1%, 100 mW, 0603 [1608 Metric], Metal Film (Thin Film) PANASONIC You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Re-Reel Packaging Options Suggested replacement for:1670194RL 1811491 in Full Reel 1670194 in Cut Tape A €5.00 re-reeling charge will be added for this product	500+ €0.0866 1000+ €0.0551 2500+ €0.0428	Restricted Item Minimum order of 500 items Multiples of 10 only Please enter a valid quantity Add Min: 500 Mult: 10	-	-	-	-	-	-	-	ERA Series	-	-	-	-	-	-	-

ERA3ARB152V	1717575 Data Sheet + RoHS	SMD Chip Resistor, 1.5 kohm, ± 0.1%, 100 mW, 0603 [1608 Metric], Metal Film (Thin Film) PANASONIC You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:1717575 1717575RL in Re-Reel	10+ €0.561 100+ €0.304 500+ €0.246 1000+ €0.199 2500+ €0.196 5000+ €0.192 25000+ €0.189 50000+ €0.188 More Pricing...	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	1.5kohm	-	100mW	0603 [1608 Metric]	± 0.1%	Metal Film (Thin Film)	High Reliability	ERA Series	75V	± 10ppm/°C	1.6mm	0.85mm	-55°C	155°C	AEC-Q200

RC0402JR-071KL	9232761 Data Sheet + RoHS Date/Lot Code	SMD Chip Resistor, 1 kohm, ± 5%, 62.5 mW, 0402 [1005 Metric], Thick Film, General Purpose YAGEO You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:9232761 9232761RL in Re-Reel 2693640 in Full Reel	10+ €0.0115 100+ €0.0064 500+ €0.0025 2500+ €0.0024 5000+ €0.0023	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	1kohm	-	62.5mW	0402 [1005 Metric]	± 5%	Thick Film	General Purpose	RC_L Series	-	± 100ppm/°C	1mm	0.5mm	-55°C	155°C	-

CRCW080516K0FKEA	1652925 Data Sheet + RoHS Date/Lot Code	SMD Chip Resistor, 16 kohm, ± 1%, 125 mW, 0805 [2012 Metric], Thick Film, General Purpose VISHAY You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:1652925 1652925RL in Re-Reel	10+ €0.0781 100+ €0.0322 500+ €0.0257 1000+ €0.0129 2500+ €0.0102 5000+ €0.01 25000+ €0.0098 50000+ €0.0096 More Pricing...	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	16kohm	-	125mW	0805 [2012 Metric]	± 1%	Thick Film	General Purpose	CRCW e3 Series	150V	± 100ppm/K	2mm	1.25mm	-55°C	155°C	AEC-Q200

ERJ3EKF1823V	2059508 Data Sheet + RoHS	SMD Chip Resistor, 182 kohm, ± 1%, 100 mW, 0603 [1608 Metric], Thick Film, Precision PANASONIC You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:2059508 2059508RL in Re-Reel	10+ €0.0538 100+ €0.0219 500+ €0.0154 1000+ €0.0089 2500+ €0.0087 5000+ €0.0085 25000+ €0.0084 50000+ €0.0082 More Pricing...	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	182kohm	-	100mW	0603 [1608 Metric]	± 1%	Thick Film	Precision	ERJ Series	75V	± 100ppm/°C	1.6mm	0.85mm	-55°C	155°C	AEC-Q200

RC0402FR-0727RL	9239049 Data Sheet + RoHS Date/Lot Code	SMD Chip Resistor, 27 ohm, ± 1%, 62.5 mW, 0402 [1005 Metric], Thick Film, General Purpose YAGEO You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:9239049 9239049RL in Re-Reel	10+ €0.0152 100+ €0.007 500+ €0.0035 2500+ €0.0028 5000+ €0.0021 10000+ €0.002 50000+ €0.0019 100000+ €0.0018 More Pricing...	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	27ohm	-	62.5mW	0402 [1005 Metric]	± 1%	Thick Film	General Purpose	RC_L Series	-	± 100ppm/°C	1mm	0.5mm	-55°C	155°C	-

RL2512FK-070R33L	1779467 Data Sheet + RoHS	SMD Chip Resistor, 0.33 ohm, ± 1%, 1 W, 2512 [6432 Metric], Thick Film, General Purpose YAGEO You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:1779467 1779467RL in Re-Reel 2693911 in Full Reel	10+ €0.486 100+ €0.184 500+ €0.183 1000+ €0.107 2000+ €0.104	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	0.33ohm	-	1W	2512 [6432 Metric]	± 1%	Thick Film	General Purpose	RL Series	-	± 600ppm/°C	6.35mm	3.2mm	-55°C	125°C	-

LR1206-R05FW	1099913 Data Sheet + RoHS Date/Lot Code	SMD Chip Resistor, 0.05 ohm, ± 1%, 500 mW, 1206 [3216 Metric], Thick Film, General Purpose TT ELECTRONICS / WELWYN You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:1099913 1099913RL in Re-Reel	5+ €0.456 50+ €0.362 250+ €0.348 500+ €0.341 1500+ €0.334 3000+ €0.327 15000+ €0.32 30000+ €0.313 More Pricing...	Restricted Item Minimum order of 5 items Multiples of 5 only Please enter a valid quantity Add Min: 5 Mult: 5	0.05ohm	-	500mW	1206 [3216 Metric]	± 1%	Thick Film	General Purpose	LR Series	-	± 100ppm/°C	3.2mm	1.6mm	-55°C	150°C	AEC-Q200

CRGH0603J27R	2331704 Data Sheet + RoHS Date/Lot Code	SMD Chip Resistor, 27 ohm, ± 5%, 200 mW, 0603 [1608 Metric], Thick Film, General Purpose TE CONNECTIVITY You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:2331704 2331704RL in Re-Reel	10+ €0.0071 250+ €0.007 1000+ €0.0068 5000+ €0.0067 10000+ €0.0065 20000+ €0.0064 100000+ €0.0062 200000+ €0.0061 More Pricing...	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	27ohm	-	200mW	0603 [1608 Metric]	± 5%	Thick Film	General Purpose	CRGH Series	-	± 200ppm/°C	1.6mm	0.85mm	-55°C	155°C	-

ERJ3EKF7500V	2059323 Data Sheet + RoHS Date/Lot Code	SMD Chip Resistor, 750 ohm, ± 1%, 100 mW, 0603 [1608 Metric], Thick Film, Precision PANASONIC You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:2059323 2059323RL in Re-Reel 2692560 in Full Reel	10+ €0.055 100+ €0.0224 500+ €0.0158 1000+ €0.0091 2500+ €0.0089	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	750ohm	-	100mW	0603 [1608 Metric]	± 1%	Thick Film	Precision	ERJ Series	75V	± 100ppm/°C	1.6mm	0.85mm	-55°C	155°C	AEC-Q200

CRCW04022K55FKED	2140807 Data Sheet + RoHS Date/Lot Code	SMD Chip Resistor, 2.55 kohm, ± 1%, 62.5 mW, 0402 [1005 Metric], Thick Film, General Purpose VISHAY You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:2140807 2140807RL in Re-Reel 2121652 in Full Reel	10+ €0.046 100+ €0.0187 500+ €0.009 2500+ €0.0072 5000+ €0.0071	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	2.55kohm	-	62.5mW	0402 [1005 Metric]	± 1%	Thick Film	General Purpose	CRCW e3 Series	-	± 100ppm/K	1mm	0.5mm	-55°C	155°C	AEC-Q200

RC0402FR-0727KL	9239405 Data Sheet + RoHS	SMD Chip Resistor, 27 kohm, ± 1%, 62.5 mW, 0402 [1005 Metric], Thick Film, General Purpose YAGEO You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:9239405 9239405RL in Re-Reel 2693596 in Full Reel	10+ €0.0135 100+ €0.0061 500+ €0.0037 2500+ €0.0023 5000+ €0.0022	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	27kohm	-	62.5mW	0402 [1005 Metric]	± 1%	Thick Film	General Purpose	RC_L Series	-	± 100ppm/°C	1mm	0.5mm	-55°C	155°C	-

RC0603JR-07470RL	9233334 Data Sheet Data Sheet + RoHS	SMD Chip Resistor, 470 ohm, ± 5%, 100 mW, 0603 [1608 Metric], Thick Film, General Purpose YAGEO You previously purchased this product. View in Order History	Each (Supplied on Cut Tape) Cut Tape Packaging Options Suggested replacement for:9233334 9233334RL in Re-Reel	10+ €0.0188 100+ €0.0082 500+ €0.0069 1000+ €0.0035 2500+ €0.0034 5000+ €0.0033 25000+ €0.0032 50000+ €0.0031 More Pricing...	Restricted Item Minimum order of 10 items Multiples of 10 only Please enter a valid quantity Add Min: 10 Mult: 10	470ohm	-	100mW	0603 [1608 Metric]	± 5%	Thick Film	General Purpose	RC_L Series	75V	± 100ppm/°C	1.6mm	0.8mm	-55°C	155°C	-
